Drag Cartel- K20A CAMSHAFT -DIC

  • $1,049.00
    Unit price per


Description

DRAG CARTEL DROP IN CAMS for Honda K Series Engines

After years of high-end race and DYNO testing DC has released a line of 8620 steel billet K-series camshafts that deliver the ultimate in high performance. Made from aerospace grade, 8620 steel billet material and CNC ground on state-of-the-art cam grinders, these DC cams deliver the utmost in rigidity at extended rpm range while reducing possible valve float. These are the best cams money can buy and are now available for all stages. The "K Series" is Honda's mass produced version of the roller rocker valve train assembly. Less friction, more rpm potential, faster action cam profiles...this engine has untapped potential.

SPECS:
Torque the intake cam gear bolt to 83 lb-ft.

Torque the exhaust cam gear bolt to 51 lb-ft.
Torque the pulse plates to 29 lb-ft.



Intake

Intake Low Speed Lobe: Duration 250° / (9.6 mm lift)

Intake High Speed Lobe: Duration 295° / (12.7mm lift)

Exhaust

Exhaust Low Speed Lobe: Duration 243° / (8.4 mm lift)

Exhaust High Speed Lobe: Duration 288°/ (12.00 mm lift)

IN STOCK READY FOR IMMEDIATE DELIVERY!!
